Single billet heating furnace


Name: Single log hot shear heating furnace


Name: Single billet heating furnace


Name: Single billet heating furnace

Description:
The long bar hot shearing furnace is a new furnace for heating and shearing aluminum bars designed for eliminating the flaws in the uses of an old short bar heating furnace. Long bar heating furnaces are classified into furnaces for heating and shearing a single long bar (FHSSLB) and furnaces for heating and shearing many long bars (FHSMLB). For a long bar heating and shearing furnace (LBHSF), the structure is reasonable, furnace body is airtight, thermal insulation is good and thermal efficiency is high. While a FHSSLB is being used, the length of an aluminum bar can be adjusted at any time, being convenient for production. Its cutting off and using aluminum bars helps avoiding wasting raw materials, unlike an old furnace which saws off aluminum bars.
The single bar heating and shearing furnace is a newly-developed technology for heating aluminum bars combining such new technologies as liquefied petroleum gas or natural gas jet reinforcement heating, hydraulic pressure hot shearing, etc. and has such advantages as flexible production organization, high automation extent, a good operating environment, low energy consumption, etc, thus quickly adopted by manufacturers.
Feature:
1. This equipment is provided with functions of aluminum bar saw bench and heating for aluminum bars, which can complete relevant operations concurrently.
2. Fuels required: liquefied petroleum gas,natural gas and town gas.
3. The lead time from the normal temperature to the operating temperature is only 20 minutes. it can reduce the energy burn-up(burn-up for continuous production:8-12m3/t.Al),and minimize the number of production workers working on the prodcution line.
4. It can slovethe problem with the replacement of aluminum bar in case of in consistent product speifications , reduce the wastage caused by the cutting operation of the short bar, and can in-crease the yield of extruded products by 5-8%.
5. Temperature variation of aluminum bar:±8℃



Multi-log shear heating furnace


Name: Multi bar for heating furnace


Name: Billet heating furnace


Name: Billet heating furnace

Name: Effective energy-saving aluminum billet heating furnace


Description:
aluminum profile billet heating furnace energy saving alum billet heating furnace is equipment which is necessary for alum profile factory and alum Profile Company. The purpose of the machine is heat up the alum billet equality, to change the alum billet machine capability and improve the quality of machining product .the machine which be made by our company has several kinds .includes fuel type, burning coal type, coal oil composite, gas type, (but this direction just use for fuel type), we can offer any kinds of product according to your request.
Specifications:
Heating Source: fuel type , electricity type, gas type.
Heating Method: Hot air circulation heating system with blower , Power 1.1KW.
Feeding type: chain driven
Heating speed: 50piece/hour
Chamber size:8000x600x350mm
Overall Dimension( Lx W x H):10000x1250x3000mm
Temperature Control: Full Automatic
Working temperature: 650℃
